Running Bond Brick Pattern Explained

A running bond brick pattern offsets the vertical mortar joints from one horizontal course to the next. In half running bond, alternate courses shift by half a unit and then return to the original alignment; in stack bond, the vertical joints remain aligned.

Related: A Soldier Course Describes Brick Orientation.

What is a running bond brick pattern?

Running bond arranges successive brick courses so that their vertical joints are offset rather than continuously aligned. A course is one horizontal row of bricks, and the vertical mortar joints between adjacent bricks provide the clearest reference for reading the pattern.

To identify the bond, trace several vertical joints through the repeating field. Running bond moves those joints sideways between successive courses, breaking up continuous vertical lines. Stack bond keeps the joints aligned.

That distinction should be applied to the regular field rather than to one isolated joint. Wall ends, openings, corners, returns, and decorative details can interrupt a pattern, and staggered joints alone should not be treated as a universal test for classifying every kind of masonry bond.

Terms such as half running bond and one-third running bond describe relative pattern geometry. For the diagrams below, one conceptual module means one repeating unit of horizontal layout. The fraction describes the intended course-to-course offset; it is not automatically a field measurement or the required length of a cut brick.

The visible pattern identifies joint arrangement. By itself, it does not establish dimensions, structural performance, reinforcement, anchorage, or code compliance.

Half running bond, course by course

In half running bond, the second course is offset by half the width of a unit relative to the first. The third course returns to the first course’s alignment, producing an alternating two-course repeat.¹

Conceptual half-running-bond diagram — not a cutting guide

Course 3:  0 module       [ brick ][ brick ][ brick ]
Course 2:  1/2 module         [ brick ][ brick ][ brick ]
Course 1:  0 module       [ brick ][ brick ][ brick ]

Read from the bottom upward:

2. Course 2: Move the starting alignment sideways by one-half of the conceptual module.
3. Course 3: Return to the starting alignment used for Course 1.
4. Following courses: Continue alternating between the two positions.

In plain language, the first course begins on the main reference line, the second begins with a conceptual half-unit offset, and the third repeats the first-course alignment. In the regular field, the vertical joints in the offset course fall near the centers of the bricks in the adjoining courses instead of lining up with their joints.

The diagram explains the relationship between courses; it is not an instruction to cut a brick to a particular dimension.

Running bond versus stack bond

Half running bond and stack bond can be distinguished by comparing their vertical joints and conceptual course starts.¹

Pattern	Vertical-joint arrangement	Conceptual course-start sequence
Half running bond	Staggered between successive courses	0, one-half, 0
Stack bond	Aligned through successive courses	0, 0, 0

In stack bond, each course maintains the same alignment. Its vertical mortar joints continue through successive courses, creating a grid-like appearance.

Half running bond alternates between two alignments. Its vertical joints appear on one set of lines in the first course and another set in the second, preventing the lines from continuing uninterrupted through the repeating field.

For a quick visual check:

• Look across several courses rather than at one local interruption.
• If the vertical joints move laterally from one course to the next, the courses are staggered.
• If the joints remain directly above one another, the courses are stacked.
• In half running bond specifically, the middle of a brick in one course appears above the joint in the adjoining course.

The brick-center test is specific to the half-unit offset. Other running-bond offsets may place the joint somewhere other than the brick’s center. This comparison describes observable geometry and does not assign a structural advantage to either pattern.

What about one-third running bond?

The cited description defines one-third running bond narrowly as a pattern in which the second course is offset by one-third of a brick, compared with the one-half-unit shift used in half running bond.¹

Those details affect how a drawing or physical layout is interpreted.

For construction documents, state each intended course start and show the complete repeat. A note such as “Course 1 = 0; Course 2 = one-third” identifies the first offset, but it does not replace a diagram or schedule defining the remaining courses.

As with half running bond, “one-third” describes a relative geometric offset.

What the pattern does not tell you

A fractional bond description identifies the relative position of joints. It does not independently provide the dimensions of a half brick, one-third closure, or another cut piece.

Converting the conceptual pattern into a physical layout requires, at minimum:

• the dimensions of the selected bricks;
• the intended mortar-joint thickness;
• the resulting masonry module; and
• the complete course-start sequence.

The bond name also does not determine minimum overlap, corner or opening details, reinforcement, anchorage, workmanship tolerances, or structural performance. Construction decisions for a wall, veneer, or other masonry assembly must instead follow the project drawings and specifications and the masonry requirements applicable to that assembly.

For visual identification, trace the regular field through several courses: laterally displaced joints indicate the running-bond arrangement discussed here, while uninterrupted aligned joints indicate stack bond. Half running bond follows the conceptual sequence 0, one-half, 0, but that sequence does not by itself determine physical cuts, dimensions, structural behavior, or code compliance.
